- Built to Last
- Dimensional Stability
- Exceptional Thermal Properties
- Chemical Resistance
- Smooth Surface and More Colors
- Diameter: 1.75mm +/- 0.03mm
- AMS 2 Pro, AMS HT & AMS Compatible
- AMS lite NOT Compatible
- 0.2 mm Nozzle NOT Compatible
- Stainless Steel Nozzle NOT Recommended
- Dry Out Before Use
- Color Code:72500
Looking for other products of Bambu Lab?
Frequently bought together with Bambu PA6-GF Green Filament
Description
Glass Fiber Reinforced Nylon PA6 Material
Bambu PA6-GF, also known as glass fiber reinforced Nylon 6, is a high-performance engineering filament designed for exceptional strength, durability, and dimensional stability. The glass fiber reinforcement significantly improves stiffness and structural performance, making it ideal for functional parts, industrial tools, and engineering components. Compared to other top-tier engineering filaments, PA6-GF also provides a more cost-effective solution for demanding applications.
Built to Last
Bambu PA6-GF is exceptionally strong and durable thanks to its glass fiber reinforcement. This enhanced structure allows printed parts to withstand heavy use, mechanical stress, and repeated loading without bending or breaking easily, making it an excellent choice for functional engineering components.
*Note: Printed parts can achieve improved toughness after absorbing a small amount of moisture.
Outstanding Dimensional Stability
PA6-GF offers excellent dimensional stability due to its glass fiber reinforcement, which significantly reduces warping compared to standard PA filaments. This allows users to print complex geometries and precision parts while maintaining accurate dimensions and structural integrity.
Exceptional Thermal Properties
Bambu PA6-GF features a high heat deflection temperature and excellent thermal stability. It can maintain its mechanical strength and structural performance even under elevated temperatures, making it suitable for demanding engineering, automotive, and industrial applications.
Excellent Chemical Resistance
PA6-GF provides strong resistance to chemicals, oils, greases, and many common solvents. This allows printed parts to perform reliably in harsh environments where exposure to industrial fluids or chemicals is common.
Smooth Surface and Multi-Color Printing
Bambu PA6-GF filaments are compatible with the Bambu Lab AMS system, allowing seamless multi-color printing. The special surface texture of the material also helps blur layer lines, resulting in a smoother surface finish compared to many traditional engineering filaments.
RFID for Intelligent Printing
All printing parameters are embedded into the RFID tag on the filament spool. When used with the Bambu Lab AMS (Automatic Material System), the printer automatically reads the filament information and applies the recommended settings.
Simply load the spool and start printing — no manual parameter adjustments required.
Wholesale & Private Label Services
We offer wholesale and private label (OEM) services for a wide range of 3D printing accessories, including build plates, hotends, and related components.
More Options
Product videos
Printing Tips
• Bambu PA6-GF needs proper drying before printing: recommended drying temperature is 80 ℃ for 8 to 12 hours in a blast drying oven, or 90 to 100 ℃ for 10 to 12 hours on heat bed. (Do not exceed 100 ℃ because the spool may deform or even melt). For more details, please refer to:Printing tips for Engineering materials on WIKI.
• To prevent the filament from absorbing moisture, it is recommended to use an airtight storage container with desiccant during printing. For more details, please refer to:Printing tips for Engineering materials on WIKI.
• To minimize warping, avoid printing large-sized high infill density models. Use enclosed printers and ensure the build plate is properly applied with glue for better print adhesion before printing.
• For better print results and more details, please refer to:Printing tips for Engineering materials on WIKI.
Post-processing Tips
• We recommend removing the support structures within 2 hours after printing to prevent them from sticking after absorbing moisture. If sticking occurs, dry the model to ease the removal.
• Placing the printed part in a convection oven set between 80 to 130 degrees Celsius for 5 to 12 hours can further enhance the strength and rigidity of the print. Note: The effectiveness of this process depends on the structure, size, and conditions of the printed model. Some models may warp or deform after annealing. For more details, please refer to:Work after Printing Finished on WIKI.
Specification
Recommended Printing Settings
| Printing Parameter | Recommended Setting |
|---|---|
| Drying Settings before Printing | 80 °C, 8 – 12 h |
| Printing and Keeping Container’s Humidity | < 20% RH (Sealed, with Desiccant) |
| Nozzle Temperature | 260 – 290 °C |
| Bed Temperature (with Glue) | 80 – 100 °C |
| Printing Speed | < 130 mm/s |
Parameters Comparison
| Property | PA6-GF | PA6-CF | PAHT-CF |
|---|---|---|---|
| Composition | PA6, glass fiber | PA6, carbon fiber | PA12 and other long-chain PA, carbon fiber |
| AMS Compatibility | YES | NO | YES |
| Dry Out Before Use | Required | Required | Required |
| Printing Speed | < 130 mm/s | < 100 mm/s | < 100 mm/s |
| Printer Type | Enclosure | Enclosure | Enclosure |
| Toughness (Impact Strength – XY, dry state) | 27.2 kJ/m² | 40.3 kJ/m² | 57.5 kJ/m² |
| Toughness (Impact Strength – XY, wet state) | 55.8 kJ/m² | 57.2 kJ/m² | 62.3 kJ/m² |
| Strength (Bending Strength – XY, dry state) | 120 MPa | 151 MPa | 125 MPa |
| Strength (Bending Strength – XY, wet state) | 71 MPa | 95 MPa | 115 MPa |
| Layer Strength (Bending Strength – Z, dry state) | 51 MPa | 80 MPa | 61 MPa |
| Layer Strength (Bending Strength – Z, wet state) | 33 MPa | 45 MPa | 49 MPa |
| Stiffness (Bending Modulus – XY, dry state) | 3670 MPa | 5460 MPa | 4230 MPa |
| Stiffness (Bending Modulus – XY, wet state) | 2120 MPa | 3560 MPa | 3640 MPa |
| Layer Adhesion (Impact Strength – Z, dry state) | 4.1 kJ/m² | 15.5 kJ/m² | 13.3 kJ/m² |
| Heat Resistance (HDT, 0.45 MPa, Dry State) | 182 ℃ | 186 ℃ | 194 ℃ |
| Saturated Water Absorption Rate (25 °C, 55% RH) | 2.56% | 2.35% | 0.88% |
Accessory Compatibility
| Category | Recommended | Not Recommended |
|---|---|---|
| Build Plate | Smooth PEI Plate, Textured PEI Plate | Cool Plate SuperTack |
| Hotend | Hotend with Hardened Steel 0.4mm / 0.6mm (recommended) / 0.8 mm | Hotend with Stainless Steel Nozzle (All Sizes) |
| Glue | Bambu Glue Stick | Bambu Liquid Glue |
| AMS & AMS lite | AMS | AMS lite |
Physical & Mechanical Properties
| Property | Value |
|---|---|
| Density | 1.14 g/cm³ |
| Vicat Softening Temperature | 210 °C |
| Heat Deflection Temperature | 182 °C |
| Melting Temperature | 219 °C |
| Melt Index | 9.0 ± 0.8 g/10 min |
| Tensile Strength | 75 ± 6 MPa |
| Breaking Elongation Rate | 3.9 ± 0.8 % |
| Bending Modulus | 3670 ± 140 MPa |
| Bending Strength | 120 ± 6 MPa |
| Impact Strength | 27.2 ± 2.2 kJ/m² |
Bambu Lab PA6-GF Lime 3D Printer Filament 1.75mm with Spool
